Specifications
| Appearance | R shape |
| Sensing distance | 5mm (Slot width) |
| Standard detection objects | Opaque objects (Size:＞1.2*1.8mm) |
| Repeat accuracy | ＜0.03mm |
| Output type | NPN open-collector |
| Switch type | Selectable L.on, D.on |
| Indicator | Red LED |
| Response frequency | 3KHz |
| Light source | Infrared LED (940nm) |
| Operating voltage | 5~24V DC |
| Voltage drop | ＜1.5V (load current 100mA, 2m cable length ) |
| No-load supply current | ≤15mA |
| Protective circuit | Surge protection , Reverse polarity protection |
| Ambient temperature | Working time: -25℃~+55℃ When saving: -30℃~+80℃ without freezing |
| Ambient humidity | Working hours: 5%~85%RH Storage: 5%~95%RH, non-condensing |
| Ambient illuminance | Incandescent lamp ≤1000Lux |
| Response time | ≤0.3ms |
| Degree of protection | IP50 |
| Material | PC |
| Connection | Connector |
In Stock: 0.0
| Stock: | 0.0 Can Dispatch Immediately |
| Factory Lead Time: | 15 Days |
| Price: |
₹ 450.00 ₹ 450.00₹ 450.00 |
