S-25W Single Output Switching Power Supply 24V, 1.1A

Product Code S-25-24
Description S-25W Single Output Switching Power Supply 24V, 1.1A
Make Xexagon
Cerificate CE
Dc output voltage 24V
Output voltage tolerance ±1%
Rated output current 1.1A
Output current range 0-1.1A
Output power 26.4W
Ripple and the noise 100mVp-p
Dc voltage adjustable scope ±10%
Start, rise, keep time 800ms,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC Loaded with
Input voltage range 90 ~132 VAC / 180-264VAC By switch 47~ 63 Hz;120~370VDC
Exchange input current 0.6 A/115 V 0.35A/ 230 V
efficiency 80%/115VAC
Impulse current Cold start current 15A/115V 30A/230V
Leakage current <0.75 mA/240VAC
Overload protection 110%~160% cut off output . Fold back current limiting, recovers automatically
Overvoltage protection 115%~135%, Protection way: hiccups, auto recovery mode
Working temperature, humidity -10℃~+60℃;20%~90 %RH
Keep temperature, humidity -20℃~+85℃;10%~95 %RH
Vibrate resistance 10 ~ 500 Hz ac, 2 G 10 min. / 1 cycle time, 60 minutes, the axis

In Stock: 5.0

Stock: 5.0 Can Dispatch Immediately
Factory Lead Time: 15 Days
Price:

₹ 470.00 470.0 INR ₹ 470.00

₹ 470.00

    This combination does not exist.

    Add to Cart
